ASTM A106 Gr C Seamless Pipes

 SPECIFICATIONS

Carbon Steel ASTM A106 Gr C Seamless Pipe are available in different grades and standards. Some of the standard features these are made available in include
Dimensions : ASTM, ASME and API
Specifications : ASTM A106 ASME SA106
Thickness : 3-12mm
End : Plain End, Beveled End, Treaded
Length : Min 3 Meters, Max18 Meters, or according to customer’s requirement
Type : Seamless
Schedules : SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules

Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of ASTM A106 Carbon Steel Grade C Seamless Pipes, which is ductile and strong, with long-wearing properties. These ASME SA 106 Carbon Steel Grade C Seamless Pipes are specially designed using premium quality material to resist heavy weights and pressure conditions. The provided ASTM A106 Carbon Steel Grade C Seamless Tubes are used for regulating flow in a pipeline, consisting of a movable disk-type element. Designed with high precision and engineered with high technologies, these ASME SA 106 Carbon Steel Grade C Seamless Pipe are used in fabrication and engineering projects. Our ASME SA 106 Grade C Seamless Pipes is used in Fertilizer Industry, Heat Exchangers, Oil Refineries, Brine Heaters, Space Research, Petrochemical industry, Engineering projects, General Piping Industry, and more. The machines that have been used to make these ASTM A106 Grade C Seamless Tubes are of the latest technology and are present in bulk for efficient production and intricate designing of the flanges.

LIST OF CARBON STEEL ASTM A106 GR C SEAMLESS PIPE

Pipe Type:

  • Bevelled End (BW)
  • Plain End Pipe (PE)
Sr No DESCRIPTION GRADE SIZE RANGE
A SEAMLESS / WELDED PIPES
1 Carbon Steel Seamless Pipes A106 / A106 / API 5L
Grade C (NACE – MR -0175)		 1/2″ – 24″
2 Carbon Steel ERW Black & Galvanized Pipes A106 Grade C – B / API 5L – A106, Grade C (NACE MR-0175) 1/2″ – 16″
4 Carbon Steel SAW Pipes API 5L / ASTM A671/ 672 ( up to Grade X-70) 12″ – 135 “



NOTE : OTHER SIZES AND GRADES ARE AVAILABLE UPON REQUEST



ASTM A106 GR C CS SEAMLESS PIPES PRESSURE RATING

Maximum working pressure of ASTM A106 Grade C Pipe at temperature 400°F

The dimensions - outside pipe diameters and wall thicknesses are according ANSI B36.10.

Nominal Bore Outside Diameter Light (A-Class) Thickness Weight Medium (B-Class) Thickness Weight Heavy (C-Class) Thickness Weight
Inch mm Inch mm mm kg/mtr mm kg/mtr mm kg/mtr
1/8″ 3 mm 0.406 10.32 1.80 0.361 2.00 2.65 0.493
1/4″ 6 mm 0.532 13.49 1.80 0.517 2.35 0.407 2.90 0.769
3/8″ 10 mm 0.872 17.10 1.80 0.674 2.35 0.852 2.90 1.02
1/2″ 15 mm 0.844 21.43 2.00 0.952 2.65 1.122 3.25 1.45
3/4″ 20 mm 1.094 27.20 2.35 1.410 2.65 1.580 3.25 1.90
1″ 25 mm 1.312 33.80 2.65 2.010 3.25 2.440 4.05 2.97
1.1/4″ 32 mm 1.656 42.90 2.65 2.580 3.25 3.140 4.05 3.84
1.1/2″ 40 mm 1.906 48.40 2.90 3.250 3.25 3.610 4.05 4.43
2″ 50 mm 2.375 60.30 2.90 4.110 3.65 5.100 4.47 6.17
2.1/2″ 65 mm 3.004 76.20 3.25 5.840 3.65 6.610 4.47 7.90
3″ 80 mm 3.500 88.90 3.25 6.810 4.05 8.470 4.85 10.1
4″ 100 mm 4.500 114.30 3.65 9.890 4.50 12.10 5.40 14.4
5″ 125 mm 5.500 139.70 – – 4.85 16.20 5.40 17.8
6″ 150 mm 6.500 165.10 – – 4.85 19.20 5.40 21.2
  • 1 in (inch) = 25.4 mm
  • 1 psi (lb/in2) = 6,894.8 Pa (N/m2) = 6.895x10-2 bar



ASTM A106 GRADE C PIPE SCHEDULE CHART & ASTM A106 GRADE C PIPE WEIGHT

ASTM A106 Grade C Pipe Dimensions and weights section modulus and gallons capacity per linear foot

Size NPS Pipe O.D. Wall Thickness Pipe I.D. Weight per Foot Standard to XXHY Schedule
Pipe #		 Section Modulus Gallon Capacity Per Linear Foot
1/2 0.84 0.109 0.622 0.85 STD 40 .0407 .0158
0.147 0.546 1.09 XHY 80 .0478 .0122
0.188 0.464 1.31 160 .0528 .0088
0.294 0.252 1.72 XXHY .0577 .0026
3/4 1.05 0.113 0.824 1.13 STD 40 .0705 .0277
0.154 0.742 1.48 XHY 80 .0853 .0225
0.219 0.612 1.95 160 .1006 .0153
0.308 0.434 2.44 XXHY .1103 .0077
1 1.315 0.133 1.049 1.68 STD 40 .1328 .0449
0.179 0.957 2.17 XHY 80 .1606 .0374
0.250 0.815 2.85 160 .1904 .0271
0.358 0.599 3.66 XXHY .2136 .0146
1 1/4 1.66 0.140 1.380 2.27 STD 40 .2346 .0777
0.191 1.278 3.00 XHY 80 .2913 .0666
0.250 1.160 3.77 160 .3421 .0549
0.382 0.896 5.22 .4110 .0328
1 1/2 1.90 0.145 1.610 2.72 STD 40 .3262 .1058
0.200 1.500 3.63 XHY 80 .4118 .0918
0.281 1.338 4.86 160 .5079 .0730
0.400 1.100 6.41 .5977 .0494
2 2.375 0.109 2.157 2.64 10 .4205 .1898
0.154 2.067 3.66 STD 40 .5606 .1743
0.218 1.939 5.03 XHY 80 .7309 .1534
0.250 1.875 5.68 .8045 .1434
0.281 1.813 6.29 .8666 .1344
0.344 1.687 7.47 160 .9806 .1161
0.436 1.503 9.04 XXHY 1.1043 .0922
2 1/2 2.875 0.120 2.635 3.53 10 .6870 .2833
0.203 2.469 5.80 STD. 40 1.0640 .2487
0.216 2.443 6.14 1.1169 .2435
0.250 2.375 7.02 1.2468 .2301
0.276 2.323 7.67 XHY 80 1.3386 .2202
0.375 2.125 10.02 160 1.6371 .1842
0.552 1.771 13.71 XXXHY 1.9971 .1280
3 3.50 0.120 3.260 4.34 1.0411 .4336
0.156 3.188 5.58 1.3122 .4147
0.172 3.156 6.12 1.4265 .4064
0.188 3.124 6.66 1.5342 .3984
0.216 3.068 7.58 STD. 40 1.7241 .3840
0.250 3.000 8.69 1.9372 .3672
0.281 2.938 9.67 2.1207 .3521
0.300 2.900 10.26 XHY 80 2.2253 .3431
0.438 2.624 14.34 160 2.8774 .2811
0.600 2.300 18.6 XXHY 3.4243 .2158
3 1/2 4.0 0.120 3.760 4.98 10 1.3776 .5768
0.226 3.548 9.12 STD. 140 2.3939 .5136
0.250 3.500 10.02 2.6001 .4998
0.281 3.438 11.17 2.8562 .4821
0.318 3.364 12.52 XHY 80 3.1400 .4617
0.636 2..728 22.87 XXHY 4.8795 .3085
4 4.5 0.120 4.260 5.62 10 1.7612 .7404
0.156 4.188 7.24 2.2354 .7156
0.188 4.124 8.67 2.6296 .6942
0.203 4.094 9.32 2.8173 .6838
0.219 4.062 10.02 3.0184 .6725
0.237 4.026 10.80 STD. 40 3.2145 .6613
0.250 4.000 11.36 3.3611 .6528
0.281 3.938 12.67 60 3.7021 .6326
0.312 3.876 13.97 4.0273 .6126
0.337 3.826 15.00 XHY 80 4.2713 .5972
0.438 3.624 19.02 120 5.1790 .5361
0.531 3.438 22.53 160 5.8997 .4822
0.674 3.152 27.57 XXHY 6.7927 .4054
5 5.563 0.188 5.187 10.80 4.1161 1.0979
0.219 5.125 12.51 4.7279 1.0716
0.258 5.047 14.63 STD. 40 5.4500 1.0391
0.281 5.001 15.87 5.8644 1.0204
0.312 4.939 17.51 6.4074 .99647
0.344 4.875 19.19 6.9358 .9696
0.375 4.813 20.80 XHY 80 7.4300 .9449
0.500 4.563 27.06 120 9.2534 .8495
0.625 4.313 32.99 160 10.7976 .7590
0.750 4.063 38.59 XXHY 12.0954 .6734
6 6.625 0.109 6.407 7.59 5 3.5769 1.6748
0.134 6.357 9.30 10 4.3475 1.6488
0.156 6.313 10.79 5.0107 1.6260
0.188 6.249 12.94 5.9351 1.5937
0.203 6.219 13.94 6.3804 1.5780
0.219 6.187 15.00 6.8261 1.5620
0.250 6.125 17.04 7.6905 1.5306
0.280 6.065 18.99 STD. 40 8.4958 1.5008
0.312 6.001 21.06 9.3416 1.4688
0.344 5.937 23.10 10.111 1.4391
0.375 5.875 25.05 10.893 1.4082
0.432 5.761 28.60 XHY 80 12.224 1.3541
0.500 5.625 32.74 13.711 1.2909
0.562 5.501 36.43 120 14.9806 1.2346
0.625 5.375 40.09 16.1821 1.1787
0.719 5.187 45.39 160 17.8243 1.0977
0.864 4.897 53.21 XXHY 20.025 .9784
1.000 4.625 60.13 21.7719 .8727
1.125 4.375 66.14 23.1237 .7809



DIFFERENT TYPES OF ASTM A106 GR C CARBON STEEL SEAMLESS PIPE

  •  ASME SA106 Grade C CS Pipes
  •  Carbon Steel SA106 B Seamless Black Round Pipes
  •  ASTM A106 Gr. C Carbon Steel Seamless Pipes
  •  ASTM A106 B Seamless Pipe
  •  ASTM A106 Gr. C Sch.40 Black Steel Seamless Pipe
  •  Carbon Steel A106 Grade C Seamless Pipe
  •  ASTM A106 Gr. C Carbon Steel Seamless Pipes
  •  ASTM A106 B Sch40 Seamless Pipe
  •  ASTM A106 Grade C Seamless Pipe Weight
  •  ASTM A106 Gr. C Carbon Steel Pipe
  •  ASTM A106 Grade C Schedule 80 SMLS Pipe
  •  ASTM A106 Grade C Seamless Pressure Pipe



CARBON STEEL A106 GRADE C SEAMLESS PIPES CHEMICAL COMPOSITION

Grade Chemical Composition (%) Max.
C Mn P Si Cu Ni Cr Mo V
B 0.3 max 0.29~1.06 0.035 0.1 min 0.4 max 0.4 max 0.4 max 0.15 max 0.08



CARBON STEEL A106 GRADE C SEAMLESS PIPE MECHANICAL PROPERTIES

Grade Mechanical Properties, Min.
Tensile Strength(Mpa) Yield Strength(Mpa)
B 415 240



APPLICATION AND MATERIAL OF A106 GRADE C CARBON STEEL SEAMLESS PIPE

  •  ASTM A106 Gr C Seamless Pipe used for Power Plants
  •  ASTM A106 Gr C Seamless Pipe used for Ship Building
  •  ASTM A106 Gr C Seamless Pipe used for Nuclear Power
  •  ASTM A106 Gr C Seamless Pipe used for Off-Shore Oil Drilling Companies
  •  ASTM A106 Gr C Seamless Pipe used for Marine Applications
  •  ASTM A106 Gr C Seamless Pipe used for Paper & Pulp
  •  ASTM A106 Gr C Seamless Pipe used for Sea Water Equipment
  •  ASTM A106 Gr C Seamless Pipe used for Fossil Fuel Power Plants
  •  ASTM A106 Gr C Seamless Pipe used for Refineries
  •  ASTM A106 Gr C Seamless Pipe used for Gas Processing
