API X56 5L PSL 2 Pipes

 SPECIFICATIONS

Trade Name : API 5L X56 PSL 2 Pipes
Sizes (Seamless) : 1/2” NB – 60” NB
Sizes (ERW): 1/2” NB – 24” NB
Sizes (SAW) : 16” NB – 100” NB
Sizes LSAW/DSAW : 16’OD TO 54′ OD (8 MM TO 50 MM THK)
Wall Thickness : 5.5mm-25.5mm,
surface : Bare, varnished, black lacquer, 3PE,FBE,Epoxy, as per customer’s requirement;
Packing : Usually in loose pieces; can be packed as customers’ special requirements

Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of  API 5L X56 PSL 2 Pipes that are widely used for pipe-to-pipe connections. API 5L X56 PSL 2 Seamless Pipes are extensively used in different machineries and various industrial processes, depending on the type of applications. With the rich industry experience and knowledge, we are able to manufacture, trade, and supply API 5L X56 PSL 2 Welded Pipes, which are provided on diverse specifications as per the demand of customers in a given time frame. API 5L X56 PSL 2 EFW Pipes has excellent resistance to oxidation, nitriding and hydrogen embrittlement for service temperature to about 600 Degree C (1110 Degree F). API 5L X56 PSL 2 ERW Pipes are widely used in Stone Crusher, Chemical, Fertilizers, Pharmaceuticals, Sugar, Steel, Cement, Mineral, Food Processing, Construction, etc.

LIST OF API 5L X56 PSL 2 PIPE

API 5L GRADE X56 PSL 2 PIPES CHEMICAL COMPOSITION

CHEMICAL COMPOSITION

mass fraction, based upon heat and product analysis % maximum carbon equivalent a
% maximum
CB SI MNB P S V NB TI other CEIIW CEPcm
Seamless & welded pipes
1320N or x 56N 0.24 0.4 1.4 0.025 0.015 0.10F 0. 05 0. 04 E 0.43 0.25
1320Q or x 56Q 0.18 0.45 1.4 0.025 0.015 0.07 0.05 0.04 E 0.43 0.25
Welded pipe
1290M or x52M 0.22 0.45 1.4 0.025 0.015 D D D E 0.43

API 5L GR X56 PSL 2 PIPES MECHANICAL PROPERTIES:

MECHANICAL REQUIREMENTS

Y.S T.S ELONGATION
Mpa(psi) Mpa(psi)
min min min
390 (56 600) 490 (71 100) f

DIFFERENT TYPES OF API 5L X56 PSL 2 PIPES

  •  API 5L X56 PSL 2 Seamless Pipe
  •  API 5L X56 CS PSL 2 Pipe
  •  API 5L Gr X56 PSL 2 LSAW Pipes
  •  API 5L X56 PSL 2 Schedule 40 Black Pipe
  •  API 5L X56 PSL 2 Carbon Steel SAW Pipes
  •  API 5L X56 PSL 2 Sch.40 Black Steel Line Pipe
  •  API 5L X56 PSL 2 Carbon Steel Pipes
  •  API 5L X56 PSL 2 Nace + Hic Line Pipes
  •  API 5L X56 PSL 2 Carbon Steel Seamless Pipes
  •  Carbon Steel API 5L X56 PSL 2 Nace + Hic Pipe
  •  API 5L X56 PSL 2 Carbon Steel HIC Tested Line Pipe
  •  API 5L Grade X56 PSL 2 Seamless Pipe
  •  API 5L X56 PSL 2 Schedule 80 SMLS Pipe
  •  API 5L X56 PSL 2 Schedule 80 DSAW Pipe
  •  API 5L X56 PSL 2 Welded Pipe Weight
  •  API 5L Gr.X56 PSL 2 SMLS Line Pipes
  •  API 5L X56 PSL 2 Round Pipes
  •  API 5L Gr X56 PSL 2 ERW Pipes

APPLICATION AND MATERIAL OF API 5L X56 PSL 2 PIPE

  •  API 5L X56 PSL 2 Pipe used for Refineries
  •  API 5L X56 PSL 2 Line Pipe used for Power Plants
  •  API 5L X56 PSL 2 Pipe used for Marine Applications
  •  API 5L X56 PSL 2 Line Pipe used for Off-Shore Oil Drilling Companies
  •  API 5L X56 PSL 2 Pipe used for Fossil Fuel Power Plants
  •  API 5L X56 PSL 2 Pipe used for Ship Building
  •  API 5L X56 PSL 2 Line Pipe used for Nuclear Power
  •  API 5L X56 PSL 2 Pipe used for Paper & Pulp
  •  API 5L X56 PSL 2 Line Pipe used for Gas Processing
  •  API 5L X56 PSL 2 Pipe used for Sea Water Equipment
