API X56 5L PSL 1 Pipes

 SPECIFICATIONS

Trade Name : API 5L X56 PSL 1 Pipes
Sizes (Seamless) : 1/2” NB – 60” NB
Sizes (ERW): 1/2” NB – 24” NB
Sizes (SAW) : 16” NB – 100” NB
Sizes LSAW/DSAW : 16’OD TO 54′ OD (8 MM TO 50 MM THK)
Wall Thickness : 5.5mm-25.5mm,
surface : Bare, varnished, black lacquer, , 3PE,FBE,Epoxy, as per customer’s requirement;
Packing : Usually in loose pieces; can be packed as customers’ special requirements

Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of API 5L X56 PSL 1 Pipes that are available in all types and pressures. We have all the in-house facilities to deliver bulk orders of API 5L X56 PSL 1 Seamless Pipe within the allocated time. API 5L X56 PSL 1 Welded Pipes is often known as Easy installation, High tensile strength, Rugged design, Elegant workout, Long Lasting, Fine texture, Fine finish, High durability, Non-corrosive, High quality, Fine Finish, Low maintenance, and more. Our company has been highly acclaimed in the field of supply, trade, import and wholesale of API 5L X56 PSL 1 EFW Pipes, which are widely used for higher temperature applications and are easily installed. We have made a position of repute on the basis of our emphasis on providing only superior grade industrial supplies of API 5L X56 PSL 1 ERW Pipes to our valued clients. With the help of professionals, our firm is capable to provide API 5L X56 PSL 1 Round Pipe, which are enormously employed owing to their longer life and durability.

LIST OF API 5L X56 PSL 1 PIPE

API 5L GRADE X56 PSL 1 PIPES CHEMICAL COMPOSITION

CHEMICAL COMPOSITION
Mass fraction, based upon heat and product analysis a
SEAMLESS PIPE
C Mn  P   V Nb Ti
maxb max.b min. max. max. max. max. max.
0.28 1.40 - 0.030 0.030 d d d
WELDED PIPE
0.26 1.40 - 0.030 0.030 d d d

API 5L GR X56 PSL 1 PIPES MECHANICAL PROPERTIES:

MECHANICAL REQUIREMENTS

Y.S T.S ELONGATION
Mpa(psi) Mpa(psi)
min min min
390 (56 600) 490 (71 100) f

DIFFERENT TYPES OF API 5L X56 PSL 1 PIPES

  •  API 5L X56 PSL 1 Seamless Pipe
  •  API 5L X56 PSL 1 Sch.40 Black Steel Line Pipe
  •  API 5L X56 PSL 1 Carbon Steel Pipes
  •  API 5L X56 PSL 1 Nace + Hic Line Pipes
  •  API 5L X56 PSL 1 Carbon Steel Seamless Pipes
  •  API 5L X56 CS PSL 1 Pipe
  •  API 5L Gr X56 PSL 1 LSAW Pipes
  •  API 5L X56 PSL 1 Schedule 40 Black Pipe
  •  API 5L X56 PSL 1 Carbon Steel SAW Pipes
  •  API 5L X56 PSL 1 Welded Pipe Weight
  •  API 5L Gr.X56 PSL 1 SMLS Line Pipes
  •  API 5L X56 PSL 1 Round Pipes
  •  API 5L Gr X56 PSL 1 ERW Pipes
  •  Carbon Steel API 5L X56 PSL 1 Nace + Hic Pipe
  •  API 5L X56 PSL 1 Carbon Steel HIC Tested Line Pipe
  •  API 5L Grade X56 PSL 1 Seamless Pipe
  •  API 5L X56 PSL 1 Schedule 80 SMLS Pipe
  •  API 5L X56 PSL 1 Schedule 80 DSAW Pipe

APPLICATION AND MATERIAL OF API 5L X56 PSL 1 PIPE

  •  API 5L X56 PSL 1 Pipe used for Refineries
  •  API 5L X56 PSL 1 Line Pipe used for Power Plants
  •  API 5L X56 PSL 1 Pipe used for Marine Applications
  •  API 5L X56 PSL 1 Line Pipe used for Off-Shore Oil Drilling Companies
  •  API 5L X56 PSL 1 Pipe used for Fossil Fuel Power Plants
  •  API 5L X56 PSL 1 Pipe used for Ship Building
  •  API 5L X56 PSL 1 Line Pipe used for Nuclear Power
  •  API 5L X56 PSL 1 Pipe used for Paper & Pulp
  •  API 5L X56 PSL 1 Line Pipe used for Gas Processing
  •  API 5L X56 PSL 1 Pipe used for Sea Water Equipment
