API X46 5L PSL 1 Pipes

 SPECIFICATIONS

Trade Name : API 5L X46 PSL 1 Pipes
Sizes (Seamless) : 1/2” NB – 60” NB
Sizes (ERW): 1/2” NB – 24” NB
Sizes (SAW) : 16” NB – 100” NB
Sizes LSAW/DSAW : 16’OD TO 54′ OD (8 MM TO 50 MM THK)
Wall Thickness : 5.5mm-25.5mm,
surface : Bare, varnished, black lacquer, , 3PE,FBE,Epoxy, as per customer’s requirement;
Packing : Usually in loose pieces; can be packed as customers’ special requirements

Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of API 5L X46 PSL 1 Pipes that are being sourced from reliable manufacturers and thus making sure of their durability and high quality. The American Petroleum Institute specification API 5L X46 PSL 1 Seamless Pipes addresses welded and seamless steel line pipe for the pipeline transportation systems in natural gas and petroleum industries. Also, these API 5L X46 PSL 1 Welded Pipeare appropriate for conveying gas, water, and oil. As these, API 5L X46 PSL 1 EFW Pipes are used for gas, water and oil transportation, they are being chosen in protracted pipelines because of inexpensiveness. API 5L X46 PSL 1 ERW Pipes are also used for pipeline steel, since they are quite resistance to crack propagation. These API 5L X46 PSL 1 Round Pipes are as well used for Line Pipe and Sour Service Line Pipes.

LIST OF API 5L X46 PSL 1 PIPE

API 5L GRADE X46 PSL1 PIPES CHEMICAL COMPOSITION

CHEMICAL COMPOSITION
Mass fraction, based upon heat and product analysis a
SEAMLESS PIPE
C Mn P V Nb Ti
maxb maxb max. max. max. max. max.
0.28 1.40 0.030 0.030 D D D
WELDED PIPE
0.26 1.40 0.030 0.030 D D D

API 5L GR X46 PSL 1 PIPES MECHANICAL PROPERTIES:

MECHANICAL REQUIREMENTS
Y.S T.S ELONGATION
Mpa(psi) Mpa(psi)
min min min
320 (46 400) 435 (63 100) 28%

DIFFERENT TYPES OF API 5L X46 PSL 1 PIPES

  •  API 5L X46 PSL 1 Carbon Steel Pipes
  •  API 5L X46 PSL 1 Nace + Hic Line Pipes
  •  API 5L X46 PSL 1 Seamless Pipe
  •  API 5L X46 PSL 1 Sch.40 Black Steel Line Pipe
  •  API 5L X46 PSL 1 Carbon Steel Seamless Pipes
  •  API 5L X46 CS PSL 1 Pipe
  •  API 5L X46 PSL 1 Schedule 40 Black Pipe
  •  API 5L X46 PSL 1 Carbon Steel SAW Pipes
  •  API 5L Gr X46 PSL 1 LSAW Pipes
  •  API 5L Gr.X46 PSL 1 SMLS Line Pipes
  •  API 5L X46 PSL 1 Welded Pipe Weight
  •  API 5L X46 PSL 1 Round Pipes
  •  API 5L X46 PSL 1 Schedule 80 SMLS Pipe
  •  API 5L X46 PSL 1 Schedule 80 DSAW Pipe
  •  API 5L Gr X46 PSL 1 ERW Pipes
  •  Carbon Steel API 5L X46 PSL 1 Nace + Hic Pipe
  •  API 5L X46 PSL 1 Carbon Steel HIC Tested Line Pipe
  •  API 5L Grade X46 PSL 1 Seamless Pipe

APPLICATION AND MATERIAL OF API 5L X46 PSL 1 PIPE

  •  API 5L X46 PSL 1 Pipe used for Refineries
  •  API 5L X46 PSL 1 Line Pipe used for Power Plants
  •  API 5L X46 PSL 1 Pipe used for Marine Applications
  •  API 5L X46 PSL 1 Line Pipe used for Off-Shore Oil Drilling Companies
  •  API 5L X46 PSL 1 Pipe used for Fossil Fuel Power Plants
  •  API 5L X46 PSL 1 Pipe used for Ship Building
  •  API 5L X46 PSL 1 Line Pipe used for Nuclear Power
  •  API 5L X46 PSL 1 Pipe used for Paper & Pulp
  •  API 5L X46 PSL 1 Line Pipe used for Gas Processing
  •  API 5L X46 PSL 1 Pipe used for Sea Water Equipment
