API X42 5L PSL 2 Pipes

 SPECIFICATIONS

Trade Name : API 5L X42 PSL 2 Pipes
Sizes (Seamless) : 1/2” NB – 60” NB
Sizes (ERW): 1/2” NB – 24” NB
Sizes (SAW) : 16” NB – 100” NB
Sizes LSAW/DSAW : 16’OD TO 54′ OD (8 MM TO 50 MM THK)
Wall Thickness : 5.5mm-25.5mm,
surface : Bare, varnished, black lacquer, , 3PE,FBE,Epoxy, as per customer’s requirement;
Packing : Usually in loose pieces; can be packed as customers’ special requirements

Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of API 5L X42 PSL 2 Pipes, which are acknowledged among customers for its sturdy design. Our clients have inspired us to create a wide range of our API 5L X42 PSL 2 Seamless Pipes, which are specially made keeping in mind the specifications and demands of the clients. Clients have enjoyed fulfillment of their exact needs and requirements of these API 5L X42 PSL 2 Welded Pipes by getting the customized products at the decent prices. The purpose of this specification is to provide standards for our API 5L X42 PSL 2 ERW Pipes suitable for use in water, conveying gas, and in both the oil and natural gas industries. We offer our esteemed clients with these API 5L X42 PSL 2 EFW Pipes that are manufactured using high grade steel, and are available in various shapes and lengths with dimensional accuracy.

LIST OF API 5L X42 PSL 2 PIPE

  • API 5L GRADE X42 PSL2 PIPES CHEMICAL COMPOSITION

    CHEMICAL COMPOSITION

    mass fraction, based upon heat and product analysis % maximum carbon equivalent a
    % maximum
    cb si mnb p s v nb ti other CEIIW CEPcm
    Seamless & welded pipes
    1290r or x42r 0.24 0.4 1.2 0.025 0.015 0. 06 0. 05 0. 04 e 0.43 0.25
    1290q or x42q 0.18 0.45 1.4 0.025 0.015 0.05 0.05 0.04 e 0.43 0.25
    Welded pipe
    1290m or  x42m 0.22 0.45 1.3 0.025 0.015 0.05 0.05 0.04 e 0.43 0.25

    API 5L GR X42 PSL 2 PIPES MECHANICAL PROPERTIES:

    MECHANICAL REQUIREMENTS

    Y.S T.S ELONGATION
    Mpa(psi) Mpa(psi)
    min min min
    245(35 500) 415(60 200) 28%

    DIFFERENT TYPES OF API 5L X42 PSL 2 PIPES

    •  API 5L X42 PSL 2 Nace + Hic Line Pipes
    •  API 5L X42 PSL 2 Schedule 40 Black Pipe
    •  API 5L X42 PSL 2 Carbon Steel Seamless Pipes
    •  API 5L X42 CS PSL 2 Pipe
    •  API 5L X42 PSL 2 Carbon Steel Pipes
    •  API 5L X42 PSL 2 Carbon Steel SAW Pipes
    •  API 5L Gr X42 PSL 2 LSAW Pipes
    •  API 5L X42 PSL 2 Seamless Pipe
    •  API 5L X42 PSL 2 Sch.40 Black Steel Line Pipe
    •  API 5L X42 PSL 2 Round Pipes
    •  API 5L X42 PSL 2 Schedule 80 SMLS Pipe
    •  API 5L Gr.X42 PSL 2 SMLS Line Pipes
    •  API 5L Grade X42 PSL 2 Seamless Pipe
    •  API 5L X42 PSL 2 Welded Pipe Weight
    •  Carbon Steel API 5L X42 PSL 2 Nace + Hic Pipe
    •  API 5L X42 PSL 2 Carbon Steel HIC Tested Line Pipe
    •  API 5L X42 PSL 2 Schedule 80 DSAW Pipe
    •  API 5L Gr X42 PSL 2 ERW Pipes

    APPLICATION AND MATERIAL OF API 5L X42 PSL 2 PIPE

    •  API 5L X42 PSL 2 Pipe used for Refineries
    •  API 5L X42 PSL 2 Line Pipe used for Power Plants
    •  API 5L X42 PSL 2 Pipe used for Marine Applications
    •  API 5L X42 PSL 2 Line Pipe used for Off-Shore Oil Drilling Companies
    •  API 5L X42 PSL 2 Pipe used for Fossil Fuel Power Plants
    •  API 5L X42 PSL 2 Pipe used for Ship Building
    •  API 5L X42 PSL 2 Line Pipe used for Nuclear Power
    •  API 5L X42 PSL 2 Pipe used for Paper & Pulp
    •  API 5L X42 PSL 2 Line Pipe used for Gas Processing
    •  API 5L X42 PSL 2 Pipe used for Sea Water Equipment
