STAINLESS STEEL 904L TUBES

SPECIFICATIONS

SS Seamless Tubes are available in different grades and standards. Some of the standard features these are made available in include
Specifications : ASTM A 312 ASME SA 312 / ASTM A 358 ASME SA 358
Dimensions : ASTM, ASME and API
Size : 1/8″NB TO 30″NB IN
SS Tubes : 1/2″ NB – 16″ NB
SS ERW Tubes : 1/2″ NB – 24″ NB
SS EFW Tubes : 6″ NB – 100″ NB
Specialized in : Large Diameter Size
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Form : Round, Square, Rectangular, Hydraulic Etc
Length : Single Random, Double Random & Cut Length
End : Plain End, Beveled End, Treaded
Type : Seamless / ERW / Welded / Fabricated / LSAW Tubes



Categories: ,
Contact Us
Request a Quote

904L Stainless Steel Tubes also offers good resistance to other inorganic acids such as hot phosphoric acid as well as most organic acids. Stainless Steel 904L Heat Exchanger Tubes was originally developed to withstand environments containing dilute sulfuric acid. The addition of copper to SS 904L Electropolish Tubes gives it corrosion resistant properties superior to the conventional chrome nickel stainless steels, in particular to sulphuric, phosphoric and acetic acids. Stainless Steel 904L Rectangular Tubes contains high amounts of expensive ingredients, such as molybdenum and nickel. Stainless Steel 904L Square Tubes is non-magnetic, and offers excellent formability, toughness and weldability. Stainless Steel 904L Round Tubes is also resistant to stress corrosion cracking and crevice corrosion. SS 904L ERW Tubes is added with copper to improve its resistance to strong reducing acids, such as sulphuric acid.



LIST OF STAINLESS STEEL 904L TUBES

Stainless Steel 904L EFW Tubes is a low carbon high alloy austenitic stainless steel which is widely used in applications where the corrosion properties of AISI 316L and AISI 317L are not adequate. SS 904L Welded Tubes is a non-stabilized austenitic stainless steel with low carbon content. Stainless Steel 904L Seamless Tubes provides full resistance in dilute sulfuric acid environments within the entire range of concentration, from 0 to 100 %. We are well a distributor of SS 904L Tubes, which is one of the few stainless steels at temperatures of up to 35 ° C / 95 ° F.



Equivalent Grades for 904L Stainless Steel Tubes

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
904L N08904 904S13 X1NiCrMoCu25-20-5 1.4539 – – SUS 890L



904L SS Welded Tube Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
904L min. – – – – – 19.0 4.00 23.00 0.10
max. 0.20 2.00 1.00 0.045 0.035 23.0 5.00 28.00 0.25



SS 904L Seamless Tubes Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
904L 490 220 35 70-90 typical –



Stainless Steel 904L Tube Physical Properties

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (m/m/0C) Thermal Conductivity (W/m.K) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
0-1000C 0-3150C 0-5380C at 1000C at 5000C
904L 8000 200 15.0 – – 13.0 – 500 850
