STAINLESS STEEL 904L PIPES

SPECIFICATIONS

904L Seamless Pipes are available in different grades and standards. Some of the standard features these are made available in include
Specifications : ASTM A 312 ASME SA 312 / ASTM A 358 ASME SA 358
Dimensions : ASTM, ASME and API
Size : 1/8″NB TO 30″NB IN
SS Pipes : 1/2″ NB – 16″ NB
SS ERW Pipes : 1/2″ NB – 24″ NB
SS EFW Pipes : 6″ NB – 100″ NB
Specialized in : Large Diameter Size
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Form : Round, Square, Rectangular, Hydraulic Etc
Length : Single Random, Double Random & Cut Length
End : Plain End, Beveled End, Treaded
Type : Seamless / ERW / Welded / Fabricated / LSAW Pipes



Categories: ,
Contact Us
Request a Quote

The temperature of Stainless Steel 904L Bush Hex Pipes should not exceed 900 Degree C (1650 Degree F) at any time and slow cooling below 649 Degree C (1200 Degree F) can cause loss of ductility. 904L Stainless Steel Pipes are also more difficult to cold work rather than other stainless steels, because of its high level of chromium content. Stainless Steel 904L Electropolish Pipes is used to make components and tools that need an extremely high temperature resistance. Buy Stainless Steel 904L Rectangular Pipes at reasonable cost from us. However, the last 10 percent of hot working in SS 904L Square Pipe has to be performed below 871 Degree C (1600 Degree F) to gain grain refinement. The hot working of Stainless Steel 904L Round Pipe is performed in between the ranges 1093 Degree C – 1177 Degree C (2000 Degree F – 2150 Degree F).



LIST OF STAINLESS STEEL 904L PIPES

Stainless Steel 904L ERW Pipes can be easily welded using most of the traditional methods except oxyacetylene welding. Differences in coefficient of thermal expansion of base and weld metal in SS 904L EFW Pipes has to be taken into consideration. Machinability of Stainless Steel 904L Welded Pipes is possible at slow speeds with positive feeds, rigid mounts and sharp tooling surfaces. SS 904L Seamless Pipes polishes well, and is good for deep drawing. We are a distributor of SS 904L Pipes, which has good weldability, brightness, and pitting corrosion resistance.



Equivalent Grades for 904L Stainless Steel Pipe

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
904L N08904 904S13 X1NiCrMoCu25-20-5 1.4539 – – SUS 890L



904L SS Welded Pipes Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
904L min. – – – – – 19.0 4.00 23.00 0.10
max. 0.20 2.00 1.00 0.045 0.035 23.0 5.00 28.00 0.25



Stainless Steel 904L Seamless Pipe Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
904L 490 220 35 70-90 typical –



Stainless Steel 904L Pipes Physical Properties

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (m/m/0C) Thermal Conductivity (W/m.K) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
0-1000C 0-3150C 0-5380C at 1000C at 5000C
904L 8000 200 15.0 – – 13.0 – 500 850
