Stainless Steel 317 Forged Threaded Elbow Fittings is a molybdenum containing, low carbon austenitic stainless steel with increased additions of chromium, nickel, and molybdenum for better corrosion resistance and increased resistance to chemical attack for sulfurous, acetic, formic, citric, and tartaric acids. Stainless Steel 317L Forged Socket Weld Tee is actually a low carbon version of grade 317, and has the same high strength and corrosion resistance as 317 steel but can produce stronger welds due to the low carbon content. SS 317 Forged Threaded Tee Fittings is often used in chemical processing, oil refineries, food processing, paper mills, photographic handling, marine applications and gas scrubbers. Due to the molybdenum content of 3 % - 4 %, Stainless Steel 317L Forged Socket Weld Fittings are more resistant to general corrosion and pitting/crevice corrosion than type 304. SS 317 Forged Threaded Fittings is primarily comprised of 18 % to 20 % chromium and 11 % to 15 % nickel along with trace amounts of carbon, phosphorus, sulfur, silicon and balanced with iron.
LIST OF STAINLESS STEEL 317/317L FORGED FITTINGS
-
- 317 STEEL FORGED THREADED FITTING
-
- SS 317L FORGED SOCKETWELD FITTINGS
SS 317L Forged Fittings is actually a higher chromium, nickel and molybdenum version of 316 stainless designed principally for increased strength and corrosion resistance. Stainless Steel 317 Forged Fittings is a modified version of stainless steel 316, and has high strength and corrosion resistance. We are a known distributor of SS 317 / 317L Forged Fittings, which are known as high-alloy steels.
Equivalent Grades for 317/317L Stainless Steel Threaded Fittings
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 317 | S31700 | – | – | 1.4541 | – | – | – |
317/317L SS Socketweld Fitting Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 317 | min. | – | – | – | – | – | 18.0 | – | 11.0 | – |
| max. | 0.8 | 2.0 | 1.00 | 0.040 | 0.03 | 20.0 | 14.0 | – | ||
SS 317/317L Forged Fittings Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 317 | 515 | 205 | 35 | 95 | 217 |
