STAINLESS STEEL 316TI TUBES

SPECIFICATIONS

SS Seamless Tubes are available in different grades and standards. Some of the standard features these are made available in include
Specifications : A312 / A269 / A358 / A249 / A409 / A778
Dimensions : ASTM, ASME and API
Size : 1/8″NB TO 30″NB IN
SS Tubes : 1/2″ NB – 16″ NB
SS ERW Tubes : 1/2″ NB – 24″ NB
SS EFW Tubes : 6″ NB – 100″ NB
Specialized in : Large Diameter Size
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Form : Round, Square, Rectangular, Hydraulic Etc
Length : Single Random, Double Random & Cut Length
End : Plain End, Beveled End, Treaded
Type : Seamless / ERW / Welded / Fabricated / LSAW Tubes



Categories: ,
Contact Us
Request a Quote

We are a well-known distributor and stockiest of SS 316Ti Tubes, which is essentially a standard 316 Stainless Steel Tubes with titanium stabilisation and is similar in principle to the titanium stabilisation of the Stainless Steel 304 Tubes to produce Stainless Steel 321 Tubes. Our Stainless Steel 316Ti Seamless Tubes is a titanium-stabilized version of Stainless Steel 316 Tubes, which is a molybdenum-bearing austenitic stainless steel. These SS 316Ti Welded Tubes is referred to as the stabilized grade of the 316 types, and also one of the two 316 stainless steels that is recommended for higher temperature situations. Our Stainless Steel 316Ti EFW Tubes has better corrosion resistance at higher temperatures than SS 316 Tubes. These Stainless Steel 316Ti Round Tubes can improve the aqueous corrosion resistance of welds made in higher carbon grades. Our Stainless Steel 316Ti Square Tubes are more resistant to general corrosion and pitting / crevice corrosion than the conventional chromium - nickel austenitic stainless steels such as SS 304 Tubes.



LIST OF STAINLESS STEEL 316TI TUBES

Buy Stainless Steel 316Ti Rectangular Tubes at reasonable cost from us. Properties are similar to those of type 316 except that these SS 316Ti Electropolish Tubes due to its Titanium addition can be used at elevated sensitisation temperatures. Our 316Ti Stainless Steel Tubes also offer higher creep, stress-rupture and tensile strength at elevated temperature. These Stainless Steel 316Ti Heat Exchanger Tubes contains a small amount — typically only 0.5 percent — of titanium.



Equivalent Grades for 316Ti Stainless Steel Tubes

Grade UNS No Old British Euronorm GOST Japanese JIS
BS En No AFNOR
316Ti S31635 320S31 X6CrNiMoTi17-12-2 1.4571 Z6CNDT17‐12 08Ch17N13M2T SUS 316Ti



316Ti SS Welded Tube Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
316Ti min. – – – – – 16.0 2.00 10.0 –
max. 0.08 2.0 0.75 0.045 0.030 18.0 3.00 14.0 –



Stainless Steel 316Ti Seamless Tubes Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
316Ti 515 205 35 75 205
