STAINLESS STEEL 316TI PIPES

SPECIFICATIONS

316Ti Welded Pipes are available in different grades and standards. Some of the standard features these are made available in include
Specifications : ASTM A 312 ASME SA 312 / ASTM A 358 ASME SA 358
Dimensions : ASTM, ASME and API
Size : 1/8″NB TO 30″NB IN
SS Pipes : 1/2″ NB – 16″ NB
SS ERW Pipes : 1/2″ NB – 24″ NB
SS EFW Pipes : 6″ NB – 100″ NB
Specialized in : Large Diameter Size
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Form : Round, Square, Rectangular, Hydraulic Etc
Length : Single Random, Double Random & Cut Length
End : Plain End, Beveled End, Treaded
Type : Seamless / ERW / Welded / Fabricated / LSAW Pipes



Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of SS 316Ti Pipes, which are used because they are not sensitive to intergranular corrosion after heating within the carbide precipitation range of 425 ° C – 850 ° C. A limitation with Stainless Steel 316Ti Seamless Pipes is that titanium does not transfer well across a high temperature arc, so is not recommended as a welding consumable. In general, Stainless Steel 316Ti Welded Pipes is referred as an alloy steel pipe when content of Manganese – 1.65 %, Silicon – 0.6 % & copper 0.6 % exceeds the limit prescribed. SS 316Ti EFW Pipes is the grade of choice for applications in the temperature range of up to about 900 ° C, combining high strength, resistance to scaling and phase stability with resistance to subsequent aqueous corrosion. SS 316Ti Round Pipes is a modification of Stainless Steel 316 Pipes with a higher titanium content, to provide improved high temperature strength.



LIST OF STAINLESS STEEL 316TI PIPES

We bring forth for our clients, an extensive array of our CS Seamless Piping, which has been manufactured by professionals who have the right amount of experience and qualifications to deal with these products. We are a well-known name for offering optimum wide range of these Carbon Steel Alloy Seamless Pipe to the clients, which is highly appreciated by them for its smooth finish, dimensional accuracy, high tensile strength, and long life.



Equivalent Grades for 316Ti Stainless Steel Pipe

Grade UNS No Old British Euronorm GOST Japanese JIS
BS En No AFNOR
316Ti S31635 320S31 X6CrNiMoTi17-12-2 1.4571 Z6CNDT17‐12 08Ch17N13M2T SUS 316Ti



316Ti SS Welded Pipes Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
316Ti min. – – – – – 16.0 2.00 10.0 –
max. 0.08 2.0 0.75 0.045 0.030 18.0 3.00 14.0 –



Stainless Steel 316Ti Seamless Pipe Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
316Ti 515 205 35 75 205
