STAINLESS STEEL 310H FLANGES

SPECIFICATIONS

SS Flanges are available in different grades and standards. Some of the standard features these are made available in include
Specifications : ASTM A182 / A240, ASME SA182 / SA240
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges etc.
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Size : 1/2″ (15 NB) to 48″ (1200NB)
Pressure Ratings : Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)



Categories: ,
Contact Us
Request a Quote

Our Stainless Steel 310H Slip On Raised Flanges is used along with hot acetic and citric acid in the food processing industry. Special consideration in these Stainless Steel 310H Blind Raised Flanges is needed to compensate for a higher coefficient of thermal expansion to avoid warping and distortion. Our Stainless Steel 310H Weld Neck Flanges is subject to carbide precipitation and sigma phase precipitants. These SS 310H Socket Weld Flanges are available at best possible prices which is another important feature exhibited by our products range. Continuous use in 425 ° C – 860 ° C range in our Stainless Steel 310H Threaded Flanges not recommended due to carbide precipitation. These SS 310H Lap Joint Flanges has good creep deformation resistance. The controlled analysis of our SS 310H Ring Joint Type Flanges empowers it to hold adequate ductility in conditions up to hard conditions to be roll or brake framed into ductility.



LIST OF STAINLESS STEEL 310H FLANGES

We are a leader in Indian markets for many years in the field of manufacturing of these Stainless Steel 310H Orifice Flanges that are required by the oilfield and petrochemical as well as other process industries. Our SS 310H Spectacle Blind Flanges is chiefly used in the heat treatment industry and the chemical process industry. The benefits of these Stainless Steel 310H Nippo Flanges include a long service life that will retain an attractive and clean finish with low maintenance cost.



Equivalent Grades for 310H Stianless Steel Flanges

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
310H S31009 – – – – – –



310H SS Flanges Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
310H min. 0.04 – – – – 24.0 – 19.0 –
max. 0.10 2.0 1.00 0.045 0.03 26.0 21.0 –



Stainless Steel 310H Flanges Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
310H 515 205 40 95 217
