STAINLESS STEEL 347/347H PIPE FITTING

SPECIFICATIONS

SS 347/347H Pipe Fitting are available in different grades and standards. Some of the standard features these are made available in include
Specifications : ASTM A403 / ASME SA403
Dimensions : ANSI/ASME B16.9, B16.28, MSS-SP-43
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Type : Seamless / Welded / Fabricated
Thickness : 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75



Categories: ,
Contact Us
Request a Quote

Our range of these Stainless Steel 347 Reducer is for all the time known for their quite a lot of features such as reliable and durable finish, powerful construction, non - corrosive, and quite easy to install. Meanwhile, buy Stainless Steel 347 Cross at reasonable cost from us. Our engineers are standing by and are ready to assist you by means of your designs for this Stainless Steel 347 Tee. In the company of current demands on technology leaping forward, we are at the forefront in offering our Stainless Steel 347 Elbow, surpassing customer expectations. This SS 347H Butt Weld Fittings are easy to get in different grades, shapes and sizes, and are tested and passed with quality check as per national and international standards. Our Stainless Steel 347 Butt Weld Fittings are thus recommended for parts fabricated by welding which cannot be subsequently annealed or for parts which must operate in service between the ranges of 800 Degree F – 1600 Degree F. As per your present and prospective needs you can purchase any quantity of this Stainless Steel 347H Pipe Fittings from us.



LIST OF STAINLESS STEEL 347/347H PIPE FITTING

We are providing our Stainless Steel 347 Pipe Fittings that are being manufactured from best quality of raw materials. We are a distinguished stockiest and distributor of SS 347 / 347H Pipe Fittings, which are available at standard and customized sizes, along with pocket - friendly and reasonable prices.



Equivalent Grades for 347/347H Stainless Steel Pipe Fitting

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
347 S34700 – X6CrNiNb18-10 1.4550 – – –



347/347H SS Welded Buttweld Fittings Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
347 min. – – – – – 17.0 2.00 9.0 –
max. 0.08 2.0 1.00 0.045 0.030 20.0 3.00 13.0 –



Stainless Steel 347/347H Seamless Pipe Fitting Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
347 515 205 40 95 201
