STAINLESS STEEL 310S PIPES

SPECIFICATIONS

310S Seamless Pipes are available in different grades and standards. Some of the standard features these are made available in include
Specifications : ASTM A 312 ASME SA 312 / ASTM A 358 ASME SA 358
Dimensions : ASTM, ASME and API
Size : 1/8″NB TO 30″NB IN
SS Pipes : 1/2″ NB – 16″ NB
SS ERW Pipes : 1/2″ NB – 24″ NB
SS EFW Pipes : 6″ NB – 100″ NB
Specialized in : Large Diameter Size
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Form : Round, Square, Rectangular, Hydraulic Etc
Length : Single Random, Double Random & Cut Length
End : Plain End, Beveled End, Treaded
Type : Seamless / ERW / Welded / Fabricated / LSAW Pipes



Categories: ,
Contact Us
Request a Quote

Stainless Steel 310S Seamless Pipes has exceptional potency and strength at cryogenic temperatures. Stainless Steel 310S Welded Pipes is very ductile and has good weldability enabling its widespread usage in many applications. Stainless Steel 310S EFW Pipes is generally used at temperatures starting from about 800 ° C or 900 ° C. SS 310S ERW Pipes has oxidation resistance to 2000 ° F. Stainless Steel 310S Round Pipes has outstanding corrosion resistance. Rapid cooling in Stainless Steel 310S Square Pipes is required to maximize corrosion resistance. SS 310S Rectangular Pipes are welded with matching electrodes and filler metals. Stainless Steel 310S Electropolish Pipes can be easily welded and processed by standard shop fabrication practices. These SS 310S Hexagonal Pipes have good resistance to oxidation in intermittent service in air up to 1035 ° C and 1050 ° C in continuous service. If subsequent aqueous corrosion resistance is needed, these Stainless Steel 310S Bush Hex Pipes often perform well in temperatures fluctuating above and below the above range.



LIST OF STAINLESS STEEL 310S PIPES

Our SS 310S Pipes have excellent resistance to oxidation and superior strength in temperatures up to 2100 ° F. These 310S Stainless Steel Pipes has a maximum dry air service temperature of 1100 º C. Our Stainless Steel 310S Pipes have resistance to hot corrosion. The high chromium and nickel content give these Grade 310S Pipe excellent oxidation resistance as well as high strength at high temperature.



Equivalent Grades for 310S Stainless Steel Pipe

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
310S S31000/S31008 – – 1.4841/1.4845 – – SUS 310 – 310S



310S SS Welded Pipes Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
310S min. – – – – – 18.0 – 8.0 –
max. 0.03 2.0 1.00 0.045 0.03 20.0 12.0 –



Stainless Steel 310S Seamless Pipe Mechanical Properties

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
310S 515 205 40 95 217



Stainless Steel 310S Pipes Physical Properties

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (m/m/0C) Thermal Conductivity (W/m.K) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
0-1000C 0-3150C 0-5380C at 1000C at 5000C
310S 7750 200 15.9 16.2 17.0 14.2 18.7 500 720
