ALLOY STEEL T5 TUBES
ALLOY STEEL T5 TUBES - Image 2
ALLOY STEEL T5 TUBES - Image 3

ALLOY STEEL T5 TUBES

SPECIFICATIONS

AS Seamless Tubes are available in different grades and standards. Some of the standard features these are made available in include
Dimensions : ASTM
Specifications : ASTM A213
Size : 1/8″NB TO 30″NB IN
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Length : Single Random, Double Random & Cut Length
Form : Round, Square, Rectangular, Hydraulic Etc
End : Plain End, Beveled End, Treaded



Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of AS T5 Tubes, which is stabilized by the addition of columbium and tantalum. We offer high qualities Alloy Steel T5 Seamless Tubes, to meet customer’s specific needs in a wide range of size. We have striking a different and vibrant place in the industry by supplying and trading a superior quality range of AS T5 Welded Tubes, which are being used in world’s most precisely demanding industries. Alloy Steel T5 EFW Tube is known for its High grade quality, Affordable prices, Superior in performance, and more. The assortment of Alloy Steel T5 ERW Tubes is made available in diverse shapes, sizes and thickness as per the needs of our customers. Alloy Steel T5 Round Tubes are designed to offer a super combination of heat resistance, toughness and strength, high temperature corrosion resistance.



LIST OF ALLOY STEEL T5 TUBES

We offer to the clients a wide range of Alloy Steel T5 Square Tubes which is manufactured using the best quality of machines and the latest technology available in the market. We provide customization of AS T5 Rectangular Tubes as per customer satisfaction with on time deliveries and affordable price. To meet the diversified requirements of our prestigious clients, we are engaged in offering a qualitative array of AS T5 Tubes, which are provided on diverse specifications as per the demand of customers in a given time frame.



Alloy Steel Seamless Tubes Tolerance

Outside Diameter OD Tolerance WT Tolerance Ovality Tolerance Cut Length Tolerance
OD≤ 12, 7 mm ± 0, 13 mm ± 15 % – + 3, 18 mm, – 0 mm
12, 7 mm < OD ≤ 38, 1 mm ± 0, 13 mm ± 10 % max, 1, 65 mm + 3, 18 mm, – 0 mm
38, 1 mm < OD ≤ 88, 9 mm ± 0, 25 mm ± 10 % max, 2, 41 mm + 4, 76 mm, – 0 mm



Grade T5 Alloy Steel Seamless Tube Chemical Composition

C, % Mn, % P, % S, % Si, % Cr, % Mo, %
0.15 max 0.30-0.60 0.025 max 0.025 max 0.50 max 4.00-6.00 0.45-0.65



AS Gr. T5 Seamless Tubes Mechanical Properties

Tensile Strength, MPa Yield Strength, MPa Elongation, % Hardness, HB
415 min 205 min 30 min 163 max
