ALLOY STEEL P92 PIPES
ALLOY STEEL P92 PIPES - Image 2
ALLOY STEEL P92 PIPES - Image 3
ALLOY STEEL P92 PIPES - Image 4

ALLOY STEEL P92 PIPES

SPECIFICATIONS

AS Seamless Pipes are available in different grades and standards. Some of the standard features these are made available in include
Dimensions : ASTM, ASME and API
Standard : ASTM A 335 / ASME SA 335
Size : 1/8″NB TO 30″NB IN
Thickness : 2.0mm – 14 mm
Outer Diameter : 19.05mm – 114.3mm
Form : Round, Square, Rectangular, Hydraulic Etc
End : Plain End, Beveled End, Treaded
Length : Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths
Schedules : SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules, upto 12mm thk



Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of AS P92 Pipes that are often used in vessel manufacturing. Alloy Steel P92 Seamless Pipes offers improved weldability and also reduces the possibility of lower corrosion resistance around welded areas. Our range of Alloy Steel P92 Welded Pipes includes boiler pipes, carriage pipes, pipes for refinery and many more. Offered Alloy Steel P92 EFW Pipes is manufactured by our adroit professionals using premium grade of steel. We offer our entire range of Alloy Steel P92 ERW Pipes at un-matched prices in the industry. Alloy Steel P92 Round Pipes is often used in Oil Refineries, Petrochemical Plants, Fertilizers Plants, Pharmaceutical Industry, Sugar Mills, Chemical Plants, and more. Alloy Steel P92 Square Pipes are developed in tandem with norms and standards set up by the industry. We are specialized in making best quality-approved packing of Alloy Steel P92 Rectangular Pipes under the guidance of our reliable engineers and other skilled workforce within affordable prices and on time deliveries.



LIST OF ALLOY STEEL P92 PIPES

Alloy Steel P92 Pipe is known for its Robustness, Compact design, High tensile strength, and more. Extensively used in power and petroleum industries, the entire range of high quality Alloy Steel P92 Pipes offered by us is highly demanded in the market. We have gained vast expertise in offering a superior range of Alloy Steel P92 Hollow Pipes, which are used for building construction and industries like oil, petrochemical, refinery and many more.



Alloy Steel P92 Seamless Pipes Outside Diameter & Tolerance

ASTM A450 Hot rolled Outside Diameter, mm Tolerance, mm
OD≤101.6 +0.4/-0.8
101.6＜OD≤190.5 +0.4/-1.2
190.5＜OD≤228.6 +0.4/-1.6
Cold Drawn Outside Diameter, mm Tolerance, mm
OD＜25.4 ±0.10
25.4≤OD≤38.1 ±0.15
38.1＜OD＜50.8 ±0.20
50.8≤OD＜63.5 ±0.25
63.5≤OD＜76.2 ±0.30
76.2≤OD≤101.6 ±0.38
101.6＜OD≤190.5 +0.38/-0.64
190.5＜OD≤228.6 +0.38/-1.14
ASTM A530 & ASTM A335 NPS Outside Diameter, inch Tolerance, mm
1/8≤OD≤1-1/2 ±0.40
1-1/2＜OD≤4 ±0.79
4＜OD≤8 +1.59/-0.79
8＜OD≤12 +2.38/-0.79
OD>12 ±1%



ASME SA335 Alloy Steel P92 Seamless Pipe Chemical Composition

Si, % Cr, % Mo, % C, % Mn, % P, % S, %
0.50 max 8.50 - 9.50 0.30 - 0.60 0.07 - 0.13 0.30-0.60 0.020 max 0.010 max



ASME SA335 AS P92 Seamless Pipe Mechanical Properties

Tensile Strength, MPa Yield Strength, MPa Elongation, %
585 min 415 min 20 min
