PT. Cahaya Bina Baja is a distributor of Alloy Steel F9 Pipe Flanges, which are created and designed in compliance with quality standards such as DIN, ANSI, etc. AS F9 Slip On Raised Flanges is an extraordinarily up-front standard in its straightforward form by means of prime chemical components specified together with mechanical qualities. The offered AS F9 Blind Raised Flanges are manufactured from the finest quality material & leading techniques in accordance with the set norms of industry. Our range of Alloy Steel F9 Weld Neck Flanges is quality tested on various parameters before being delivered to clients. Our company is one of the best manufacturers of Alloy Steel F9 Socket Weld Flanges in the state with high degree of reliability and guaranteed goods manufactured by using superb quality raw materials in affordable prices. Our firm is successfully meeting the requirements of our customers by offering a qualitative range of Alloy Steel F9 Threaded Flanges, which are checked in terms of quality on numerous quality parameters for delivering the flawless range from our end.
LIST OF ALLOY STEEL F9 FLANGES
-
- ALLOY STEEL ASTM A182 FLANGES
-
- AS FLANGES
We supply Alloy Steel F9 Lap Joint Flanges to clients at reasonable prices in various sizes and shapes. Knowing us as one of the leading companies, we are engaged in offering a wide range of AS F9 Ring Joint Type Flanges, which are usually obtainable through pipe thread ends or by means of plain cut ends.
Alloy Steel F9 Flanges Standards / Types And Pressure Class
| ASME/ANSI B 16.5 | Welding Neck Flange, Slip on Flange, Blind Flange, High Hub Blind Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Ring Type Joint Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| ASME/ANSI B 16.47 | Welding Neck Flange, Blind Flange [Series A & B] |
| PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
| ASME/ANSI B 16.36 | Welding Neck Flange, Slip on Flange, Threaded Flange |
| PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
| BS 4504 SEC 3.1 | Welding Neck Flange, Hubbed Slip on Flange, Hubbed Threaded Flange, Lapped Pipe End Flange, Plate Flange, Loose Plate Flange, Loose Plate With Weld Neck Flange, Blank Flange |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange |
| PRESSURE CLASS | PN 2.5 TO PN 400 |
| BS 1560 BOSS | Welding Neck Flange, Socket Welding Flange, Slip-On Flange, Blind Flange, Screwed Boss Flange, Lapped Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| BS10 | Welding Neck Flange, Plate Slip-On Flange, Screwed Boss Flange, Slip-On Boss Flange, Blind Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
Chemical Composition of Grade F9 Alloy Steel Flanges
| Grade | C | Mn | Si | S | P | Cr | Mo |
| A182 F9 | 0.15 | 0.3 - 0.6 | 0.5 - 1 | 0.03 | 0.03 | 8 - 10 | 0.9 - 1.1 |
Mechanical Properties of ASTM A182 Alloy Steel F9 Flanges
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| A182 F9 | 380 | 585 | 20 |
