SUPER DUPLEX STEEL UNS S32750 PIPES

SPECIFICATIONS

Steel UNS S32750 Welded Pipes are available in different grades and standards. Some of the standard features these are made available in include
Specifications : ASTM A790 / ASME SA790, ASTM A789 / ASME SA A789
Dimensions : ASTM, ASME and API
Schedule : SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Outer Diameter : 6.00 mm OD up to 250 mm OD, Sizes up to 12” NB
Thickness : 0.3mm – 50 mm
Type : Seamless / ERW / Welded / Fabricated / CDW
Form : Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded

Category:

PT. Cahaya Bina Baja is an acknowledged manufacturer and exporter of Super Duplex Steel UNS S32750 Pipes, which has good weldability and very high mechanical strength. Our Super Duplex Steel UNS S32750 Seamless Pipes has inferior alloying rates when likened with comparable austenitic and ferritic grades by means of machinery erosion conflict in chloride encompassing atmospheres because of its augmented yield and tensile power. These Super Duplex Steel UNS S32750 Welded Pipes is often used for sewage treatment, desalination plants, seawater cooling, etc. When forming requires more than 10 % cold deformation in our Super Duplex Steel UNS S32750 EFW Pipes, solution hardening and quench are recommended. These Super Duplex Steel UNS S32750 ERW Pipes delivers outstanding confrontation to inanimate acids, particularly those comprehending chlorides. Our Super Duplex Steel UNS S32750 Round Pipes cannot be toughened by heat action but sturdier surface powers can be attained by cold functioning.

These Super Duplex Steel UNS S32750 Square Pipes has grouping of features given by ferritic and austenitic structure, together with first-rate workability and weldability. Packing of our Super Duplex Steel UNS S32750 Rectangular Pipes will be done according to international standard in bundles strapped by strips then into containers to avoid any damage. Solution annealing of these Super Duplex Steel UNS S32750 Electropolish Pipe should be performed at the temperature range from 1025 Deg C to 1125 Deg C followed by being quenched in water or rapidly cooled by other means.

UNS S32750 Super Duplex Pipes Chemical Composition

S32750 / S32760 C N P Si Mn Mo Ni Cr S Other
0.030 0.24/0.32 0.035 0.80 1.20 3.0/5.0 6.00/8.00 24.0/26.0 0.020 Cu:0.50



Super Duplex Steel S32750 Pipe Mechanical Properties

S32750 / S32760 Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
7.8 g/cm3 1350 °C (2460 °F) Psi – 80000 , MPa – 550 Psi – 116000 , MPa – 800 15 %



Equivalent Grades for S32750 Super Duplex Pipe

STANDARD UNS WERKSTOFF NR.
Super Duplex S32750 S32750 1.4410
Super Duplex S32760 S32760 1.4410
