PT. Cahaya Bina Baja is an approved supplier of Super Duplex Steel UNS S32760 Forged Pipe Fittings, which features high resistance to pitting corrosion and chloride-rich environments. While involving extended exposure to temperatures more than 572 Degree F, use of Super Duplex UNS S32760 Forged Threaded Fittings is not recommended. The superior content of chromium for Super Duplex UNS S32760 Forged Socket Weld Fittings makes enormously strong to constant decomposition by carbon-based acids such as acetic acid. Super Duplex 2507 Forged Fittings has high resistance to abrasion and cavitation erosion, and also has excellent mechanical properties. Super Duplex 2507 Forged Threaded Fittings is 10 % lighter than grade 316 steel, ideal for sub-zero service, and more cost effective than nickel alloys. Regarding cold work-ability in Super Duplex 2507 Forged Socket Weld Fittings, care is required as proof stress is high and elongation is low in comparison with Alloy 304. Super Duplex UNS S32760 Forged Threaded Tee Fittings cannot be hard-bitten by conservative heat actions; nevertheless this is work toughening steel.
-
- SUPER DUPLEX STEEL UNS S32760 FORGED THREADED FITTING
-
- SUPER DUPLEX STEEL UNS S32760 FORGED SOCKETWELD FITTINGS
Super Duplex UNS S32760 Forged Socket Weld Elbow has a wide and diverse range of oil & gas production environments. Super Duplex UNS S32760 Forged Threaded Cross has an improved pitting corrosion confrontation when compared through the normal austenitic types. Super Duplex UNS S32760 Forged Socket Weld Reducer is widely used in hydropower, oil & gas, pressure vessels, structural components, pulp & paper, and chemical tankers.
UNS S32760 Super Duplex Forged Fittings Chemical Composition
| S32750 / S32760 | C | N | P | Si | Mn | Mo | Ni | Cr | S | Other |
| 0.030 | 0.24/0.32 | 0.035 | 0.80 | 1.20 | 3.0/5.0 | 6.00/8.00 | 24.0/26.0 | 0.020 | Cu:0.50 |
Super Duplex Steel S32760 Forged Fitting Mechanical Properties
| S32750 / S32760 | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
Equivalent Grades for Super Duplex UNS S32760 Forged Fittings
| STANDARD | UNS | WERKSTOFF NR. |
| Super Duplex S32750 | S32760 | 1.4410 |
| Super Duplex S32760 | S32760 | 1.4410 |
